Description

Max. width of workpiece – 508mm
Max. thickness of workpiece – 203mm
Max. depth of cut – 8mm
Min. length of workpiece – 200mm
Cutterhead
Number of knives – 3 pcs
Diameter – 80mm
Cutting circle – 84mm
Speed – 5200 rpm
Table size
Width – 562mm
Length – 713mm
Feed Rolls
In-feed (sectional) – 76mm-one
Out-feed (solid) – 60mm-one
Table roll – 72mm-two
Feed rate – 8mpm
Motor power – 5hp
Overall dimensions – 1108 x 762 x 1136mm
Packing dimensions – 1280 x 800 x 1200mm
Net weight – 420 kgs
Gross weight – 520 kgs
