Description

HEATING UNIT
Heating Power : 18 kW.
Total Power : 20 kW.
Heating chamber dimensions 3800 x 1250 mm.
Max. working temperature 230oC.
Uniform heat distribution inside heating chamber.
RIBEX ROCO hot air circulation system.
Tight closing lid and 150 mm heat insulated walls.
Heat resistant wire oven grill and portable stainless steel perforated plate 2000 x 1000 mm.

VACUUM FORMING UNIT
Table surface dimensions 4100 x 1300 mm.
Multi hole durable metal table for balanced air suction.
Rotary vane GERMAN Becker Vacuum Pump VT 4.40.
Vacuum pressure max 9t/m2 – displacement 40 m3/h.
Silicone membrane rubber | 800-1000 % elongation.
Pneumatic Vertical Movement Press System allows to work up to 800 mm. height for solid surface shaping.
with optional High-Membrane (Max.molding height up to 950 mm.)
with optional powerful 100 m3/h. Becker Vacuum Pump for higher performance.

CONTROL UNIT
PLC and HMI Touch Screen controller (24 VDC).
Easy to operate with multilingual menu.
Digital on-screen vacuum gauge, heating time and vacuum time counters.
Alarm Page, Input/Output Pages, Buzzer with light.
Preset program menu for different workshops.
Test, Manual or Automatic program running.
