Description

Tension 400V
Weight 710Kg
Spindle – motor power 7,5 PS/hp (option 10 PS/hp)
Dimensions cast iron table 1200mm x 705mm
Table height 930mm
Interchangeable shaft diameter 30 / 40 / 50 mm 1″ 1/4
Spindle length 180mm
Spindle stroke 205mm
R.p.m 3000/4500/6000/7000
Max. diameter and height table opening 320mm x 95mm
Sliding table dimensions 760mm x 500mm
Sliding table stroke 1050mm
Dust suction ports 120mm
